Complete System TM702.13 L-TEK

The Ikusi TM702.13 L-TEK is a complete industrial radio remote control system featuring the TM702 eight-button transmitter paired with the R13 L-Tek receiver. It is the higher-channel variant of the TM70 series, providing two additional control channels over the six-button TM701 system.

The extra two pushbuttons make the TM702 the right choice for applications where operators need to control auxiliary functions beyond basic crane movements — for example, a secondary hoist, trolley rotation, or a magnet/grab release. The transmitter layout keeps all eight buttons within comfortable thumb reach, so operators can work a full shift without fatigue.

Like the TM701, the TM702 uses Ikusi's L-Tek frequency-hopping digital communication for reliable, interference-resistant control. Each system ships factory-paired with unique digital coding — there is no risk of cross-activation between systems operating on the same site. The transmitter is IP65-rated, built to withstand dust, rain, and the general abuse of industrial environments. A mushroom-head emergency stop is prominently positioned for instant access.

The included R13 L-Tek receiver accepts 24-48V AC/DC supply and provides relay outputs for direct contactor switching. Installation is straightforward for any qualified electrical engineer familiar with crane control panels.

Supplied as a genuine Ikusi product from UK stock by Lumen Electronics, an authorised Ikusi/Danfoss distributor. Full technical support available.

If six channels are sufficient for your application, the Ikusi TM701 system offers the same build quality at a lower price point.

Key Specifications

• Transmitter: TM702 (8 single-speed pushbuttons)
• Receiver: R13 L-Tek
• Technology: L-Tek (frequency-hopping digital)
• Transmitter protection: IP65
• Emergency stop: Mushroom-head, transmitter-mounted
• Battery: BT06K 4.8V NiMH (included)
• Receiver supply voltage: 24-48V AC/DC
• Receiver outputs: Relay contacts

Compatibility

• BT06K replacement battery
• CB70 battery charger (recommended)
• P70 spare pushbutton set
• R13 L-Tek replacement receiver
• TM701 system (6-button alternative)

What's Included

• 1x Ikusi TM702 eight-button transmitter
• 1x Ikusi R13 L-Tek receiver
• 1x BT06K battery pack (fitted)
• Transmitter wrist strap
• Receiver mounting hardware
